Product Features
- 3 Segments: Automatic Loading Machine with Scanner, X-RAY Automatic Inspection, Automatic Identifying of Defects
- Fully Automatic Inline Detection of Welding Components
- Programmable and Automatic Recording of Motion Path for Accurate Positioning and Repeatability
- Real-Time Monitoring of Radiation Values
Specifications
X-ray Tube
| Tube Type | Reflective Sealed Micro-Focus X-ray Tube |
| Voltage Range | 40 - 90 KV |
| Electricity Range | 10 -200 uA |
| Max Output Power | 8W |
| Micro Focus Size | 5 - 15 um |
Flat Panel Detector
| Detector Type | TFT Industrial Dynamic Flat Panel Detector |
| Pixel Matrix | 1648 x 1644 |
| Field of View | 160 x 160 mm |
| Resolution | 5.11 Lp/mm |
| Frame (1 x 1) | 30 fps |
| AD Conversion Bit | 16 Bits |
Equipment
| Dimensions | 1.5M Board: 6200 L x 1600 W x 2100 H 2M Board: 7700 L x 1600 W x 2100 H mm |
| Input Power | 220V 10A / 110V 15A 50-60Hz |
| Track Width | 300 - 500 mm adjustable (automatic) |
| Operation System | Industrial Computer WIN10 64Bit |
| Net Weight | 4500 kg |
