Case Study: STENCIL-FREE PRECISION UNLEASHED: Mastering 200mm BGA Scaling

How a Singapore Semiconductor Manufacturer Scaled Large BGA Reballing up to 200 mm Using Toki Laser Reballing

Customer Profile

• Industry: Semiconductor manufacturing

• Location: Singapore

• Application: Large-format processor BGA reballing and rework
• Package Size: 120 mm and above (scalable to 200 mm)

• Ball Size: 0.25–0.75 mm
• Environment: High-value, high-mix production with strict quality control

The site supports high-performance processor packages used in enterprise and data center applications, where scrap risk is unacceptable.

The Challenge

As BGA sizes increased beyond 120 mm, the site faced growing risk in:

• Maintaining placement accuracy across very large arrays
• Managing thermal stability during rework
• Scaling toward future 200 mm packages
• Supporting high-mix programs without tooling bottlenecks


Conventional stencil-based reballing was evaluated but not preferred due to:

• Stencil lead time dependency
• Tooling inventory management
• Flux handling variability
• Limited flexibility for engineering changes


The requirement was clear:

Precision, scalability, and flexibility without tooling dependency.

The Solution Implemented

Toki deployed a laser reballing and large-format rework cell capable of:

• Supporting BGA sizes up to 200 mm
• Handling 0.25–0.75 mm solder balls
• Pad-by-pad programmable placement
• Multi-zone controlled thermal rework
• Recipe save/load with profile logging

Laser reballing was selected exclusively to eliminate stencil dependency and improve process flexibility.

Results & Strategic Impact

While specific data remains confidential, operational outcomes included:

• Stable reballing capability for 120 mm+ packages
• Scalability toward 200 mm device roadmap
• Elimination of stencil procurement delays
• Improved placement consistency for high-value devices
• Reduced process variability linked to flux handling
• Faster new package introduction cycles

Strategically, the site gained:

• Size scalability
• Mix flexibility
• Reduced scrap exposure
• Local technical support assurance

Laser reballing aligned with their high-value, high-mix manufacturing model.

Customer Testimony

“Laser reballing provides the precision and flexibility required for our large-format, high-value packages. Eliminating stencil dependency supports our high-mix environment, and local technical support was an important factor.”

Request a Process Evaluation

If you are managing:

• 120 mm+ BGA packages
• 0.25–0.75 mm solder balls
• High-value semiconductor devices
• Scalability toward 200 mm


Speak to a Toki automation specialist to assess laser reballing feasibility and large-format rework stability.
